- Number of axes : 6

- Number of spindles : 2

MAIN SPINDLE

- Spindle speeds : 5.000 [rpm]

- Max. bar diameter : 65 [mm]

- Max. turning diameter : 600 [mm]

- C axis indexing precision : 0.0001 [Ⱍ

COUNTER-SPINDLE

* Max. turning diameter : 600 [mm]

- Spindle indexing precision : 0.0001 [Ⱍ

TURNING-MILLING SPINDLE

- X/Z stroke : 685/1075 [mm]

- Y stroke : +/-125 [mm]

- B Axis stroke : +/-120 [Ⱍ

- B axis indexing precision : 0.001 [Ⱍ

- Tool type : CAPTO C5

- Spindle speeds : 12.000 [rpm]

TOOL CHANGER

- Auto. Tool Changer type : Loading arm

- Tool magazine capacity : 80

POWER SUPPLY

- Supply voltage : 400 [V]

- Total installed power : 95 [kVA]

WEIGHT & DIMENSIONS

- Machine floor space : 6725 x 2884 [mm]

- Machine height : 3177 [mm]

- Machine weight : 16300 [kg]

MACHINE HOURS

- Number of hours under power : 48553 [h]

Equipment

- CNC : Mori MSX-711 III

- Coolant tank

* with high-pressure pump : 20 [bars]

* with oil separator : ECODE IIP 600C

- Spindle cooling unit

* Coolant through spindle

- Chips conveyor

- Oil mist extractor

- Tool probe

- Workpiece probe

- Tool breakage detection

- Chuck 3 jaws : 2

- Counter-spindle equipped with zero point for Erowa pallet
