- Number of axes : 4

MILLING SPINDLE

- Tool holder type : ISO50

- Spindle power : 17 [kW]

- Spindle speeds : 10-4000 [rpm]

- Number of spindle hours : 29050 [h]

LINEAR AXES

- Travels on X/Y/Z axes : 1600/1100/1000 [mm]

- Rapid traverses rates (X/Y/Z) : 12 [m/min]

- Cutting feed rates (X/Y/Z) : 0.0001-8 [mm/min]

TOOL CHANGER

- Auto. Tool Changer type : Loading arm

- Tool magazine capacity : 120

TABLE

- Table dimensions : 1700 X 1200 [mm]

- Maximum weight upon table : 4000 [kg]

- Distance table / spindle nose (min./max.) : 85-1085 [mm]

PALLET CHANGER

- Pallet size : 1200 X 1200 [mm]

- Pallets number : 2

POWER SUPPLY

- Supply voltage : 400 [V]

- Total installed power : 55 [kW]

WEIGHT & DIMENSIONS

- Machine floor space : 51100 X 7250 [mm]

- Machine height : 3610 [mm]

- Machine weight : 15000 [kg]

MACHINE HOURS

- Number of hours under power : 94683 [h]

- Number of working hours : 29050 [h]

Equipment

- CNC : Siemens 840 D

- Interface : Ethernet / RS232 / USB / PCMCIA

- Interactive programming : Shopmill

- Electronic handwheel

- Linear scales

- Rigid tapping

- 3 colors status lamp

- Type of divisor : full 4th axis

* Travel 4th axis : 360 [Ⱍ

* Indexing precision 4th axis : 0.0001 [Ⱍ

* with high-pressure pump : 50 [bars]

* With paper filtering unit

* With cooling unit for coolant

- Coolant through spindle

- Chips conveyor

- Oil mist extractor

- Spindle cooling unit

- Tool probe : Renishaw laser NC4

- Workpiece probe : Renishaw
